Shield lead carrier-JX-VC22-Series

Shield lead carrier-JX-VC22-Series


Lead Shielded Transport Carriers provide a convenient and safe way for healthcare workers in the nuclear medicine field to store and transport syringes or vials containing radionuclides. The vessel uses a stainless steel lead-lined process and overlapping lid design, which provides both double layer protection and reduces leakage of lead and radioactive liquids. It is also equipped with a fixed or rotatable handle to facilitate safe transportation by medical personnel. The Lead Shielded Transport Carriers can hold up to 15 ml syringes and are ideal for use in nuclear medicine laboratories, treatment rooms, dispensing rooms, PET/CT examination rooms and other industrial production flaw detection sites. If there are other requirements on size specifications and shielding thickness, please send email to us for communication.

Email: admin@cnrayshield.com

Product details

Shield lead carrier-JX-VC22-Series

Product model : JX-VC22-series

Inner size: 241*76*69mm,

Out size: 268*103*118  (LxWxH)

This portable syringe carrier provides a convenient, safe way of storing and transporting syringes or vials containing radionuclides

Type: JX-VC22-03- lead thickness 3mm

Type: JX-VC22-06- lead thickness 6mm

Type: JX-VC22-10- lead thickness 10mm

Type: JX-VC22-20- lead thickness 20mm

Product Parameters

Material 304 Stainless steel Lead
Lead Density 11.34g/cm3
Inner Size 241x76x69mm
Out Size(LxWxH) 268x103x118mm
Lead Shield thickness 3-20mm
Size of accommodated Syringe 1ml,2ml,5ml,10ml
Standard ASTM,GB
Certification ISO 9001
