Mobile Lead Barrier-with glass

Mobile Lead Barrier-with glass


Nuclear medicine is an evolving field with innovations in technology, diagnostic procedures and therapeutic purposes. With the increasing and widespread use of nuclear medicine treatments, the need for shielding also increases. PET Radiation Shield Barrier Mainly made of stainless steel material, filled with more than 99.94% of the pure lead plate, generally divided into three specifications: single, double and triple. It has lead glass observation window in the middle and above, which is convenient for medical staff to observe and understand the patient on the side and make timely treatment. PET Radiation Shield Barrier It can be applied in x-ray examination, CT room, PET room, dental or operating room and other medical areas to shield the harmful ionizing radiation from radioactive isotopes for medical staff. With strong lockable casters, operators can move the screen from one department to another according to their own needs.

Email: admin@cnrayshield.com

Product details

Mobile Lead Barrier-with glass

Mobile Lead Barrier-JX-LS001

Mobile Lead Barrier-JX-LS010

Mobile Lead Barrier-JX-LS015

  • Materials: lead and stainless steel
  • Overall dimensions: 900 x 1800 mm
  • Lead glass dimension: 300 x 400 mm
  • Lead thickness 2 mm Pb



  • Materials: lead and stainless steel
  • Overall dimensions: 900 x 1800 mm
  • Lead thickness 10 mm Pb



  • Materials: lead and stainless steel
  • Overall dimensions: 900 x 1800 mm
  • Lead thickness 15 mm Pb

Product Parameters

Material Lead and Stainless Steel
Lead Equivalent Thickness 0.5-10mm Pb
Size(HxWxT) 1600mm X 800mm X 45mm or Customized
Height 1320mm-2000mm
Overall Dimension 1600mmx2000mm
Lead Glass Window(LxH) 600mmx800mm
Delivery Time 15–20 days
Standard ASTM,GB
Certification ISO 9001
